Basic Information:
- Brand: Epson
- Model: DX11, FA09121, F1080-A1, FA090300030
- Original or Not: Original
- New or Used: Brand New ( The one Removed from desktop printer)
- Warranty Policy: No Warranty
- Technology: Micro-Piezo
- Compatible Ink Types: Eco-Solvent, Water-Based, UV
Product Details:
The Epson XP600, released around 2018, is a 6-channel printhead derived from the Epson F1080. Originally designed for water-based ink printer use, it has become popular for use with eco-solvent, UV, and thermal transfer inks. It is currently one of the most cost-effective entry-level options in the UV and DTF printing markets. It is compatible with most Direct-to-Film (DTF) printer models. Although its image resolution and durability are limited, its low cost, easy installation, and wide compatibility make it the preferred choice for many small format printing devices.
Epson XP 600 Print Head Specifications
| Technology | Micro-Piezo |
| Dimensions | 84.9 x 57.2 x 42.6 mm |
| Weight | 60 g |
| Number of nozzles | 1080 |
| Nozzle pitch/nozzle row | 1/180 inch |
| Nozzle rows | 6 rows |
| Max. number of colour inks | 6 colours (180 dpi/colour) |
| Nozzle resolution | 180 npi/row, 360 npi/2 rows |
| Effective print width | 25.4 mm |
| Jetting Frequency | 46 kHz (single mode); 11.52 kHz (multimode) |
| Droplet volumes | 4.5, 9, 20, 40 pl (multimode) |
| Viscosity range | 3-5 mPa･s |
| Ink type | UV ink, eco-solvent ink |
Epson XP 600 Print head Applications:
1. Sublimation Printing: Used for printing on T-shirts, mugs, fabrics, and other items; suitable for customized small batch production.
2. DTF Printing: Suitable for Direct to Film (DTF) heat transfer printing on garments, fabrics, bags .etc
3. Small UV Flatbed Printers: Used for personalized printing on phone cases, glass, acrylic boards, and other small UV printed products.
4. Entry Level Eco-Solvent Printers: The solvent XP600 print head is suitable for small advertising signs, graphic printing, and label production.
