Basic Information:

• Brand: Ricoh
• Model: GH2220
• Original or Not: Original
• Place of Origin: Japan
• New or Used: Brand New
• Warranty Policy: No Warranty

Ricoh GH2220 Printhead Description:

Inheriting the characteristics of Ricoh printheads, the Ricoh GH2220 printhead is made of all steel, is corrosion-resistant, and has stable performance. It has a minimum ink droplet of 3PL, which allows the printing effect of the Ricoh printhead to be extremely delicate. The printer features a printing width of up to 32.4 mm and offers high printing speeds of 4 passes: 16 m²/h, 6 passes: 10 m²/h, and 8 passes: 7 m²/h. They are also extremely outstanding among products in the same price range. The conventional service life is about 1 year, and the high-strength service life is about 6 months.

Ricoh GH2220 Printhead Specifications

Method	Piston pusher with metallic diaphragm plate
Print Width	32.4 mm (1.28″)
Number of nozzles	384
Nozzle spacing (Within a row)	1/150″ (0.1693 mm)/row
Nozzle spacing (row-to-row distance)	0.931 mm
Max. number of colors inks	2 colors
Drop volume	Binary mode: 3-5 pl / Gray-scale: 21±2 pl*depending on the ink
Jetting frequency	Binary mode: 30 kHz / Gray-scale: 24 kHz
Compatible ink	Solvent, Aqueous

Ricoh GH2220 Printhead Applications

The Ricoh GH2220 printhead delivers high performance for sign graphics, textiles, and coding & marking markets.
