Basic Information:
- Brand: Mimaki
- Model: MP-M010010
- Original or Not: Original
- New or Used: Brand New
- Warranty Policy: No Warranty
- Used for: Mimaki UJF-3042 printer
Mimaki UJF3042 Print head ( Model: MP-M010010) Description
This original Mimaki printhead Unit Assy is suitable for Mimaki UJF-3042 printers. This is the original Mimaki part (number M010010 replacing M013773).
The Ricoh GEN4 (MH2420) printhead, featuring 384 nozzles, a firing frequency of 30 kHz, and a 7-picoliter droplet size with greyscale capability, is designed for Mimaki UJF-3042 printer use. This genuine printhead includes a built-in heater and thermistor for optimal performance.
Mimaki UJF3042 Print head ( Model: MP-M010010) Specifications
| Number of nozzles | 384 (2*192 channels), staggered |
| Nozzle spacing (within a row) | 1/150’’ (0.1693mm)/row |
| Temperature control | Integrated heater and thermistor |
| Operator temperature range | Up to 60℃ |
| Native drop volume | 7pl |
| Drop volume range | 5-25pl with greyscale |
Printer Compatibility:
Mimaki UJF-3042
Mimaki UJF-3042FX
Mimaki UJF-3042HG
Mimaki UJF-6042
